Operating the monitor | 87
2. When connecting HDMI + USB A to C to computer 1 and Thunderbolt
TM
4 to
computer 2:
2
HDMI
1
1
3
2
USB A to C
3
Thunderbolt
TM
4
NOTE: The USB-C connection currently supports video and data transfer.
Ensure USB Selection for HDMI is set to USB-C.
Exit
USB-C
PIP/PBP
USB
DP assign to
HDMI assign to
Personalize
Others
Menu
Input Source
Display
Color
Brightness/Contrast
Show KVM Setup Guide Select
UltraSharp 27 Monitor
Thunderbolt(90W)
NOTE: As the Thunderbolt (90W) port supports the DisplayPort Alternate
Mode, there is no need to set USB Selection for Thunderbolt (90W).
NOTE: When connecting to different video input sources not shown above,
follow the same method to make correct settings for USB Selection to pair
the ports.
NOTE: The built-in KVM switch allows you to control up to 2 computers
from a single set of keyboard and mouse connected to the monitor.
To Next Page
