Dell U3011 - Page 26


When the monitor does not support a particular resolution mode you will see the following message:
This means that the monitor cannot synchronize with the signal that it is receiving from the computer. See Monitor Specifications for the
HorizontalandVerticalfrequencyrangesaddressablebythismonitor.Recommendedmodeis2048x1280(VGAinputsource)/2560x
1600 (DVI/DisplayPort input sources) / 1920 x 1200 (HDMI input source).

YouwillseethefollowingmessagebeforetheDDC/CIfunctionisdisabled.
When monitor enters Power Save mode, the following message appears:


Activate the computer and wake up the monitor to gain access to the OSD
If you touch any button other than the power button one of the following messages will appear depending on the selected input:
VGA/DVI-D/DisplayPort/HDMI/Component input

