Dell U3011 - Back View; Side View

Back View
Side View
3
Shortcut Key 3 - Input Source (Default)
4
Menu
5
Exit
6
Power (with power light indicator)
NOTE: 1~5 are capacitive touch sensor keys, which are activated by placing your finger on the blue LED.
Back view
Back view with monitor stand
Label
Description
Use
1
VESA mounting holes (100 mm x 100
mm - behind attached VESA Plate)
Wall mount monitor using VESA-compatible wall mount
kit (100 mm x 100 mm).
2
Security lock slot
To help secure your monitor.
3
Barcode serial number label
To contact Dell for technical support.
4
Dell Soundbar mounting brackets (2)
To attach the optional Dell Soundbar.
5
Regulatory label
Lists the regulatory approvals.
6
Service tag label
Refer to this label if you need to contact Dell for
technical support.
7
Cable management hole
Helps organize cables by placing them through the hole.
Left view
Right view
Label
Description
1
Card reader: for details, see Card Reader Specifications.
2
USB downstream port.
3
USB downstream port (support up-to 1.5 A charging current).
NOTE: To use the USB connectors on your monitor, connect the USB cable to your computer and the USB upstream connector to your monitor.
