Dell U3011 - Physical Characteristics; Environmental Characteristics

Physical Characteristics
Environmental Characteristics
sync(H+V) 0.3 volt, 75 ohm input impedance
Synchronization input signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on
green)
AC input voltage/frequency/current
100 to 240 VAC / 50 Hz/60 Hz +/- 3 Hz / 2.5 A
(Max.)
Inrush current
120 V: 42 A (Max.) at 0
o
C
220 V: 80 A (Max.) at 0
o
C
Connector type
15-pin D-subminiature, blue connector; DVI-D,
white connector; HDMI/DisplayPort, black
connector; Component
Signal cable type
DVI: Detachable, DVI-D, Solid pins, shipped
attached to the monitor
DisplayPort: Detachable, DisplayPort, Solid pins,
shipped detached from the monitor
Analog: Detachable, D-Sub, 15 pins, shipped
detached from the monitor
High Definition Multimedia Interface: Detachable,
HDMI, 19 pins
Component
NOTE: The component, and HDMI cables are not
included with the monitor.
Dimensions (with stand)
Height (Compressed)
481.3 mm (18.95 inches)
Height (Extended)
571.3 mm (22.50 inches)
Width
694.5 mm (27.34 inches)
Depth
211.3 mm (8.32 inches)
Dimensions (without stand)

Height
453.3 mm (17.85 inches)
Width
694.5 mm (27.34 inches)
Depth
94.4 mm (3.72 inches)
Stand dimensions

Height (Compressed)
323.2 mm (12.72 inches)
Height (Extended)
413.2 mm (16.27 inches)
Width
349.4 mm (13.76 inches)
Depth
211.3 mm (8.32 inches)
Weight

Weight with packaging
15.3 kg (33.76 lb)
Weight with stand assembly and cables
12.6 kg (27.72 lb)
Weight without stand assembly
(For wall mount or VESA mount considerations -
no cables)
9.3 kg (20.40 lb)
Weight of stand assembly
2.6 kg (5.69 lb)
Temperature

Operating
5°to35°C(41°to95°F)
Non-operating
Storage: -20°to60°C(-4°to140°F)
Shipping: -20°to60°C(-4°to140°F)
Humidity

Operating
10% to 80% (non-condensing)
Non-operating
Storage: 5% to 90% (non-condensing)
Shipping: 5% to 90%(non-condensing)
Altitude

