Dell U3818DW - Page 42

42 | Operating the Monitor
PIP/PBP Mode
Adjusts the PIP/PBP (Picture in Picture/Picture by Picture) mode to
PIP Small, PIP Large, or PBP. You can disable this feature by selecting
Off.
I
II
I
II
III
PBP
PIP Large
PIP Small
PIP/PBP (Sub)
Select between the different video signals that may be connected to
your monitor for the PIP/PBP sub-window.
PIP Location
Select PIP sub-window position.
Use
or to browse and to select Top-Left, Top-Right,
Bottom-Right, o
r Bottom-Left.
USB Select
Switch
Select to switch between the USB upstream sources in PIP/PBP
mode.
Audio
Allows you to set the audio source from the main window or the
sub-window.
Video Swap
Select to swap videos between main window and sub-window in
PIP/PBP mode.
Contrast (Sub)
Adjust the contrast level of the picture in PIP/PBP Mode.
Press the
button to increase the contrast and press the
button to decrease the contrast.
