Dell Vostro 3267 - Installing the WLAN Card

Installing the WLAN card
1. Insert the WLAN card to the connector on the system board [1].
2. Connect the WLAN cables to the connectors on the WLAN card[ 2] .
3. Place the plastic tab and tighten the M2x3.5 screw to secure the WLAN card to the system board [3].
