Dell Vostro 3267 - System Board Removal and Installation

2. Press until the release latch springs back into place and secures it.
3. Install the:
a. drive cage
b. 3.5-inch hard drive chassis
c. cooling shroud
d. front bezel
e. cover
4. Follow the procedures in After Working Inside Your Computer.
System board
Removing the system board
1. Follow the procedure in Before working inside your computer.
2. Remove the
a. cover
b. bezel
c. expansion cards
Disassembly and reassembly
53
