Dell Vostro 3590 - Installing the M.2 2280 Solid-State Drive or Intel Optane Memory - Optional

Installing the M.2 2280 Solid-state drive or Intel Optane
memory - Optional
Steps
1. Slide and insert the tab of the solid-state drive/Intel Optane into the solid-state drive/Intel Optane slot [1, 2].
2. Tighten the captive screw that secures the thermal plate to the palmrest and keyboard assembly [3].
3. Replace the single (M2x3) screw that secures the thermal plate to the palmrest and keyboard assembly [4].
