Replacing the microphone
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Slide the microphone module into the slot on the display-assembly base.
2 Replace the screw (M2x2.5) that secures the microphone module to the display-
assembly base.
3 Route the microphone cable through the routing guides on the display-assembly
base.
4 Connect the microphone cable to the system board.
Post-requisites
1 Replace the system-board shield.
2 Replace the back cover.
3 Replace the stand.
47
