Removing the speakers
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the stand.
2 Remove the back cover.
3 Remove the system-board shield.
Procedure
1 Disconnect the speaker cable from the system board.
2 Remove the four screws (M3 4+7.1 XZN) that secures the speaker to the
display-assembly base.
3 Lift the speaker (SPK1) from the display-assembly base.
4 Note the routing of the speaker cable and remove the speaker cable from the
routing guides.
61
