Removing the display panel
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the stand.
2 Remove the back cover.
3 Remove the system-board shield.
Procedure
1 Disconnect the touch-screen cable (optional) from the system board.
2 Peel o the tape that secures the display cable to the connector on the system
board.
3 Using your nger tips, push the securing clips on the display cable inwards and
disconnect it from the system board.
4 Disconnect the display-backlight cable from the display panel.
69
