Removing the camera
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the stand.
2 Remove the back cover.
3 Remove the system-board shield.
Procedure
1 Disconnect the camera cable from the system board.
2 Remove the two screws (M3x5) that secure the retractable-camera assembly to
the display-assembly base.
3 Slide and lift the retractable-camera assembly out of the display-assembly base.
48
