Replacing the speakers
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Using the alignment posts on the display-assembly base, place the speakers on
the display-assembly base.
2 Replace the four screws (M3 4+7.1 XZN) that secure the speakers to the display-
assembly base.
3 Route the speaker cable through the routing guides on the display-assembly
base.
4 Connect the speaker cable to the system board.
Post-requisites
1 Replace the system-board shield.
2 Replace the back cover.
3 Replace the stand.
63
