Replacing the display panel
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Note the positions of the four jig screws on the display panel.
2 Place the display-assembly base in its upright position, and slide the display panel
into the display-assembly base.
3 Push the display cable and the touch-screen cable (optional) through the slot on
the display-assembly base.
77
