Dell W26C - Side I;O-Board; Removing the Side I;O-Board

Side I/O-board
Removing the side I/O-board
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the stand.
3. Remove the cable cover (optional).
4. Remove the back cover.
5. Remove the hard drive.
6. Remove the system-board shield.
7. Remove the bottom cover.
8. Remove the rear-I/O bracket.
About this task
The following image indicates the location of the side I/O-board and provides a visual representation of the removal procedure.
72 Removing and installing components
