58 Appendix A
51 Lease Time Optional but recommended.
52 Option Overload Optional.
53 DHCP Message Type Recommended.
54 DHCP Server IP
Address
Recommended.
55 Parameter Request
List
Sent by appliance.
57 Maximum DHCP
Message Size
Optional (always sent by thin client).
58 T1 (renew) Time Optional but recommended.
59 T2 (rebind) Time Optional but recommended.
61 Client identifier Always sent.
161 Server (ftp/http/https) Optional string. If this is an IP address or
resolvable hostname, the protocol is assumed
to be FTP; however, it may be the leading
portion of a URL that specifies another
protocol. If using the URL form, it should not
include a trailing slash (for example, http://
server.example.com or ftp://192.168.0.1).
162 Root path to the
server (ftp/http/https)
Optional string. The relative directory starting
from the root directory must be given. For
example, on an FTP server, the full directory
may be C:/Inetpub/ftproot/wyse, where
wyse is the directory that contains the INI files.
In this example, the correct string value for this
DHCP option is /wyse.
On a Linux server, an FTP user-based directory
might be /home/test/wyse. In this example, if
the FTP user is test, then the FTP root path is
/wyse and not the full path (/home/test/wyse).
This value should use URL path notation (start
with a forward slash, /, and use a forward slash
as folder separators).
181 Wyse PN Server Optional string. IP address or FQDN of the
PNLite server.
182 Wyse Admin List Optional string. DHCP equivalent of the
DomainList ini file parameter.
184 Server Username Optional string. Username to use when
authenticating to the server specified in Option
161.
Table 3 DHCP Option Tags, Continued
Option Description Notes
