28 Hard Drive(s)
4
Remove the memory module(s) (see "Removing the Memory Module(s)"
on page 17).
5
Remove hard drive 1 and/or hard drive 2 from the computer base:
• Remove the four screws that secure the hard-drive assembly to the
computer base.
• Using the pull-tab, slide the hard-drive assembly to disconnect it from
the connector on the system board.
• Lift the hard-drive assembly out of the computer base.
Hard drive 1
Hard drive 2
1 pull-tab 2 hard-drive assembly
3 screws (4)
