Dell XPS L701X - Replacing the Coin-Cell Battery

52 Coin-Cell Battery
Replacing the Coin-Cell Battery
1 Follow the instructions in "Before You Begin" on page 9.
2 With the positive side facing up, snap the coin-cell battery into the battery
socket on the system board.
3 Replace the palm-rest assembly (see "Replacing the Palm-Rest Assembly"
on page 40).
4 Replace the optical drive (see "Replacing the Optical Drive" on page 34).
5 Follow the instructions in step 5 in "Replacing the Hard Drive(s)" on
page 30.
6 Replace the memory module(s) (see "Replacing the Memory Module(s)"
on page 18).
7 Replace the module cover (see "Replacing the Module Cover" on page 16).
8 Replace the battery (see "Replacing the Battery" on page 14).
1 coin-cell battery 2 plastic scribe
1
2
