40 Palm-Rest Assembly
Replacing the Palm-Rest Assembly
1
Follow the instructions in "Before You Begin" on page 9.
2
Slide the touch-pad cable into the system-board connector and press down
on the connector latch to secure the cable.
3
Slide the control-strip cable into the system-board connector and press
down on the connector latch to secure the cable.
4
Place the palm-rest assembly on the top cover and gently snap the
palm-rest assembly into place.
5
Close the display and turn the computer over.
6
Replace the three screws that secure the palm-rest assembly to the base
cover.
7
Replace the optical drive (see "Replacing the Optical Drive" on page 34).
1 control-strip cable connector 2 touch-pad cable connector
3 top cover 4 palm-rest assembly
