Display 63
8
Connect the appropriate antenna cables to the Mini-Cards(s) on your
computer (see "Replacing the Mini-Card(s)" on page 23).
9
Replace the keyboard (see "Replacing the Keyboard" on page 45).
10
Replace the palm-rest assembly (see "Replacing the Palm-Rest Assembly"
on page 40).
11
Replace the optical drive (see "Replacing the Optical Drive" on page 34).
12
Replace the two screws that secure the display assembly to the base cover.
13
Follow the instructions in step 5 in "Replacing the Hard Drive(s)" on
page 30.
14
Replace the memory module(s) (see "Replacing the Memory Module(s)"
on page 18).
15
Replace the module cover (see "Replacing the Module Cover" on page 16).
16
Replace the battery (see "Replacing the Battery" on page 14).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
Display Bezel
Removing the Display Bezel
CAUTION: The display bezel is extremely fragile. Be careful when removing it to
prevent damaging the bezel.
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the display assembly (see "Removing the Display Assembly" on
page 59).
3
Push the display bezel outwards to release it from the tabs that secure the
display bezel to the back cover.
4
Using your fingertips gently pry the outside edge of the display bezel off
the back cover.
5
Lift the display bezel off the display assembly.
