44 Keyboard
CAUTION: The keycaps on the keyboard are fragile, easily dislodged, and time-
consuming to replace. Be careful when removing and handling the keyboard.
CAUTION: Be extremely careful when removing and handling the keyboard.
Failure to do so could result in scratching the display panel.
10
Turn the keyboard over and place it on the top cover.
11
Lift the connector latch and pull the pull-tab to disconnect the keyboard
backlight cable from the system-board connector.
12
Lift the connector latch and pull the pull-tab to disconnect the keyboard
cable from the system-board connector.
1 screws (4) 2 keyboard
3 tabs (5) 4 top cover
