Dell XPS M1330 User Manual

Adding and Replacing Parts 125
Keyboard
For more information about the keyboard, see "Using the Keyboard and
Touchpad" on page 37.
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on the back of the computer).
NOTICE: To help prevent damage to the system board, you must remove the battery
from the battery bay before you begin working inside the computer.
Removing the Keyboard
1 Follow the procedures in "Before You Begin" on page 117.
2 Remove the Hinge Covers and Center Control Cover (see "Hinge Covers
and Center Control Cover" on page 122).
3 Remove the two M2 x 2-mm screws at the top of the keyboard.
NOTICE: The keycaps on the keyboard are fragile, easily dislodged, and time-
consuming to replace. Be careful when removing and handling the keyboard.
4 Carefully slide the keyboard toward the back of the computer.
NOTICE: Be extremely careful when removing and handling the keyboard. Failure
to do so could result in scratching the display panel.

Dell XPS M1330 Specifications

General

Processor	Intel Core 2 Duo (various models)
Display	13.3-inch
RAM	Up to 4GB DDR2
Optical Drive	Slot-loading DVD+/-RW
Card Reader	8-in-1 card reader
Resolution	1280 x 800
Graphics	Intel GMA X3100 or NVIDIA GeForce 8400M GS
Storage	64GB SSD
Operating System	Windows Vista
Weight	1.8 kg (4 pounds)
Battery	6-cell lithium-ion
Wireless	Wi-Fi 802.11a/g/n
Ports	HDMI, VGA, Ethernet
Bluetooth	Bluetooth 2.0
Audio	Integrated stereo speakers
Webcam	2.0 MP
Battery Life	Up to 4 hours
