Dell XPS M1330 User Manual

Adding and Replacing Parts 143
Replacing the Card
1 Replace the card at an angle to slide it under the securing tabs in the card
compartment.
2 Connect the cable to the card.
Coin-Cell Battery
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on the back of the computer).
NOTICE: To help prevent damage to the system board, you must remove the battery
from the battery bay before you begin working inside the computer.
1 card 2 securing tabs (2)
3cable
321

Dell XPS M1330 Specifications

General

Processor	Intel Core 2 Duo (various models)
Display	13.3-inch
RAM	Up to 4GB DDR2
Optical Drive	Slot-loading DVD+/-RW
Card Reader	8-in-1 card reader
Resolution	1280 x 800
Graphics	Intel GMA X3100 or NVIDIA GeForce 8400M GS
Storage	64GB SSD
Operating System	Windows Vista
Weight	1.8 kg (4 pounds)
Battery	6-cell lithium-ion
Wireless	Wi-Fi 802.11a/g/n
Ports	HDMI, VGA, Ethernet
Bluetooth	Bluetooth 2.0
Audio	Integrated stereo speakers
Webcam	2.0 MP
Battery Life	Up to 4 hours
