Dell Z9100-ON - LED Behavior

LED behavior
The following Z9100–ON system LED behavior is seen during open networking installation environment (ONIE) operations:
Figure 5. Z9100–ON LEDs
1
Master LED 2 System LED
3 Locator LED 4 QSFP28 LED
5 SFP+ LED 6 Stack ID
7 SFP+ LED 8 RJ45 Ethernet Management Port LEDs
9 Fan LED 10 Power LED
Table 1. Z9100–ON LED behavior
LED Description
Master LED
• O—Switch is in Stacking Slave mode.
• Solid Green—System is in Stacking Master or Standalone
mode.
System LED
• O—No power.
• Solid Green—Normal.
• Blinking Green—POST is in process.
• Solid amber—Major system error.
• Blinking amber—Minor system alert.
Locator LED
• O—Locator is idle.
• Blinking blue—Locator is functioning.
SFP+ LED
• O—No link.
• Solid green—Link is active.
• Flashing green—port activity.
RJ45 Ethernet Port LEDs
• O—No link.
The Z9100–ON system 9
