3. Operation Instructions
The power selector has five positions:
- Main supply AC (110V-120V) - DC 12V - Gas - Switch off (2 positions)
Gas Operation
Prior to starting gas operation, open the gas cylinder valve and the shut-off valve for
gas supply to the refrigerator.
After initial operation, servicing or changing gas cylinders etc., the gas pipes may
contain some air which should be allowed to escape by depressing the button (D).
This will ensure that the flame lights right away.
1. Set the power selector knob (A) to gas mode. See right fig.
2. Depress the safety valve button (D) and hold it down while depressing the
igniter button (B).
3. Check the flame indicator (C) to see whether the flame is alight. The pointer
should move from red to green section after the flame is lighted.
4. Keep the safety valve button (D) depressed for a further 10-15 seconds.
5. Release the safety valve button (B) and again check that the flame is alight.
Note: If the battery ignition fails to spark, you might need to replace the battery.
AC Operation
1. Set the power selector knob (A) to AC mode. See right Fig.
2. Have the AC power connected to the refrigerator.
The AC power should comply with what is specified in the data
plate. Any difference in values may result in damages to the
refrigerator!
DC Operation
Set the power selector knob (A) to DC mode. See right fig.
The DC mode is only designed to be used when driving. Otherwise
your battery will be discharged within a few hours!
To terminate any power mode, gas, AC or DC, turn the knob A to either of two OFF positions.
9
A: Power selector B: Battery igniter C: Flame indicator D: Safety valve E: Thermostat
