Controls description
1. Multifunction main oven thermostat knob
2. Multifunction main oven switch knob
3. Front left burner control knob
4. Rear left burner control knob
5. Fish burner control knob
6. Rear right burner control knob
7. Front right burner control knob
8. Conventional oven switch knob
9. Conventional oven thermostat knob
10. Electronic programmer (main oven only)
Pilot lamp:
11. Main oven thermostat indicator light
12. Conventional oven thermostat indicator light
Figure 26
10 1 2 3 4 5 6 7 8
CONTROL PANEL
9
1211
Please note: This appliance incorporates a safety cooling fan which you will hear
operating whenever the oven or grill are in use. This fan is to reduce the external
temperature of the appliance and cool the internal components.
