DeLonghi GSS603 - Removing Oven Door (Type B); Reassembling Oven Door (Type B)

19
Removing the oven door
The oven door can easily be removed as
follows:
– Open the door to the full extent (fig.
20A).
– Attach the retaining rings to the hooks
on the left and right hinges (fig. 20B).
– Hold the door as shown in fig. 20.
– Gently close the door and withdraw the
lower hinge pins from their location (fig.
20C).
– Withdraw the upper hinge pins from
their location (fig. 20D).
– Rest the door on a soft surface.
– To replace the door, repeat the above
steps in reverse order.
Fig. 20D
Fig. 20C
Fig. 20B
Fig. 20A
TYPE B
Fig. 20
