21
Fig. 23
Fig. 22
Levelling
The cooker is equipped with a 4 levelling
feet which must be fitted to the base of
the cooker in the following manner:
– Place the cooker on its back as shown
in the figure 23.
– Screw the 4 leveling feet to the cooker.
– Stand the cooker and levelling it by
screwing or unscrewing the feet with a
spanner.
Stability bracket
We recommend a stability bracket is fitted to the cooker.
The type shown in fig. 22 can be purchased from most
plumbers merchants and do it yourself (D.I.Y.) shops.
Wall fixing
Floor fixing
Brackets
Existing
slot in rear
of cooker
Dotted line showing the
position of cooker when fixed
Dimension is in millimetres
3
Outline of cooker
backplate at the
engagement slot
