DeLonghi GSS603 - Injector Selection Table; Air Required for Gas Combustion

26
3 - Table for the choice of the injectors
INCREASE OF AIR NECESSARY FOR GAS COMBUSTION (2 m
3
/h x kW)
BURNERS Air necessary for combustion [m
3
/h]
Auxiliary (A)
2,00
Semi-rapid (SR) 3,50
Rapid (R) 6,00
Oven 7,40
Grill 5,00
G 30 - 28-30 mbar G 20
BURNERS G31- 37 mbar 20 mbar
Auxiliary (A) 1,00 0,30 27 50 – 72 –
Semi-rapid (SR) 1,75 0,45 32 65 – 97 –
Rapid (R) 3,00 0,75 42 85 – 115 –
Oven 3,70 1,00 42 92
fully open * 140 5 *
Grill 2,50 – – 80 fully open * – 120 4 *
Nominal
Power
[kW]
Reduced
Power
[kW]
Ring opening
[mm]
Ø injector
[1/100 mm]
By-pass
[1/100 mm]
Ring opening
[mm]
Ø injector
[1/100 mm]
By-pass
[1/100 mm]
GB
Cat: II 2H3+
adjustable
*
= Reference value
