14. THOROUGH CLEANING OF MILK CARAFE
Clean the milk carafe as described below:
1. Release the lid (E1)by turning clockwise: the reference
mark on the lid must be aligned with the symbol
(g. 24);
2. Now lift the lid (g. 25).
3. Pull out the milk intake tube (35).;
1
35 36
4. Turn the milk spout at right angles to the body and pull
until completely detached (g. 36).
5. Press the button (E5)to separate the connector (g. 37).
37
2
1
6. Wash in a dishwasher (recommended) or by hand as in-
dicated below:
• In a dishwasher: Rinse all the above components and
the milk container under hot running drinking water (at
least 40 °C), then place them in the top basket of the dish-
washer and run a wash programme at 50 °C, e.g. standard
ECO.
• By hand: Rinse all the components and the milk container
thoroughly with hot running drinking water (at least 40 °C)
to remove all visible milk residues, making certain to direct
the water through all the holes of the lid (g. 38). Next,
immerse all the components in a solution of hot drinking
water (at least 40° C) and washing up liquid for at least 30
minutes. Rinse all the components described above thor-
oughly under hot drinking water, rubbing each one individ-
ually between ngers and thumbs.
38 39
7. Rinse the milk carafe connector (E6) thoroughly (g. 39).
Take particular care to ensure that there are no milk resi-
dues in the air channel (see enlargement) (g. 40): scrape
the channel clean if need be , using a toothpick;
40
8. Dry all the components with a clean dry cloth;
9. Reassemble all the lid components;
10. Close the carafe: ret the lid (the reference mark on the lid
must be aligned with the symbol) then turn toward
the symbol until locked in position (g. 28).
15. CLEANING THE INFUSER
Important!
The infuser (A6) cannot be removed while the machine is on.
1. Press the button (B1)to turn the machine o;
2. Remove the water tank (A9);
3. Open the infuser door, positioned on the right hand side
(g. 41);
4. Press the two coloured release buttons inwards (g. 42), at
the same time pulling the infuser outwards;
