Error! No text of specified style in document. DNS-24, DNT-T103, & DNT-T221 Application Guide
Page 26 of 35
Document Edition 3.1
OUTPUT FUNCTIONS & TYPES (DNT-T103 and DNT-T221 Only)
Regardless of model, any triac outputs are capable of switching up to 24 VAC at a maximum of 0.5 A each, and
may be configured for any of a number of output functions and types. Only the DNT-T221 supports two
0-10v outputs, up to a maximum of 20 mA each. Note that not all applications support all the options listed.
FUNCTIONS
Function Description LCD Code
MUX The associated output will be MUXed and not controlled by the
local algorithm, or not used at all.
Mu
0
Heating The associated output is connected to 1st stage heating.
H1
10
The associated output is connected to 2nd stage heating.
H2
20
The associated output is connected to 3rd stage heating.
H3
30
Cooling The associated output is connected to 1st stage cooling.
C1
40
The associated output is connected to 2nd stage cooling.
C2
50
The associated output is connected to 3rd stage cooling.
C3
60
Fan The associated output is connected to an intermittent fan.
Fn1
70
The associated output is connected to a constant fan.
FnC
80
The associated output is connected to a manually controlled fan.
FnM
90
Compressor The associated output is connected to a HPU compressor.
CMP
100
Reversing Valve The associated output is connected to a HPU reversing valve.
rEU
110
Humidifier The associated output is connected to a humidifier.
HUM
120
TYPES
Output Type Description Action LCD Code
Binary Provides ON/OFF control with a triac output. Direct
bi
0.0
Reverse
-bi
0.1
PWM Provides modulating control using a Pulsed Width
Modulation signal with a triac output.
Direct
Pu
0.2
Reverse
-Pu
0.3
Analog Provides modulating control using a 0-10v analog
signal (DNT-T221).
Direct
An
0.4
Reverse
-An
0.5
Flow Damper
(Analog)
Provides modulating control using a 0-10v analog
flow damper (DNT-T221 & VAV).
N/A
Ad
0.6
Time
Proportioned
Provides modulating control using a Time
Proportioned signal with a triac output.
Direct
tP
0.8
Reverse
-tP
0.9
Tri-State Provides modulating control using triac outputs 1 & 2
for a tri-state actuator (DNT-T103).
N/A
tr
1.0
Flow Damper
(Tri-State)
Provides modulating control using triac outputs 1 & 2
for a tri-state flow damper (DNT-T103 & VAV).
N/A
Fd
1.1
Note that Box Mode affects how the flow damper functions in both VAV and VVT applications. Refer to page
13 for operating information on Box Mode, and page 14 regarding Controller Operation.
