Error! No text of specified style in document. DNS-24, DNT-T103, & DNT-T221 Application Guide
Page 32 of 35
Document Edition 3.1
APPENDIX
A. LCD Object Property Values (for GCL Programming)
The following is a table of LCD object properties and associated values that can be used in GCL programming in
a DAC/DSC product for BACstats when connected on its LINKnet network.
LCD Property Name Values & Description Notes
Line1 For sending a value to Line 1
Line2 For sending a value to Line 2
Line3 For sending a value to Line 3
Line1Units 0 = º icon is turned off
1 = º icon is turned on
Only available with V3.30
DAC/DSC firmware.
Line2Units 0 = º icon is turned off
1 = º icon is turned on
Only available with V3.30
DAC/DSC firmware.
Line3Units 0 = No Unit icons
1 = º icon only
2 = ºC
3 = ºF
4 = %
5 = AM
6 = PM
Only available with V3.30
DAC/DSC firmware.
Blink 0 = Blinking is disabled
1 = Entire LCD display blinks
Occupancy 0 = No House/Man (Disabled)
1 = House only (Unoccupancy)
2 = House & Man (Occupancy)
The values shown are for V3.30
DAC/DSC firmware. For V3.22
firmware, the values of 1 and 2
are reversed.
Sun 0 = Sun icon is turned off
1 = Sun icon is turned on
Applicable only for V3.22
DAC/DSC firmware.
Moon 0 = Moon icon is turned off
1 = Moon icon is turned on
Applicable only for V3.22
DAC/DSC firmware.
SunMoon 0 = No Sun or Moon (Disabled)
1 = Moon only
2 = Sun only
Applicable only for V3.30
DAC/DSC firmware.
Fan 0 = No Fan icons - All turned off
1 = Fan icon only
2 = Fan with Air Flow Wave 1
3 = Fan with Wave 1 & Wave 2
4 = Fan with Wave 1, Wave 2, Wave 3
Heating 0 = Heating icon is turned off
1 = Heating icon is turned on
Cooling 0 = Cooling icon is turned off
1 = Cooling icon is turned on
Humidity 0 = Humidity icon is turned off
1 = Humidity icon is turned on
