Delta Controls BACstat II Series User Manual

Delta Controls
Document Edition 3.1
Page 7 of 35
Service Tool Main Menu Options
Menu Item Description
SEr
Displayed on line 2 of the LCD (center screen) to indicate you are at the Main menu
of the Service Tool Mode.
[Option] Service Tool Mode has these following main menu options, which you rotate
through using the arrow keys. Press the NEXT or PREVIOUS buttons to select the
option and penetrate deeper.
•
CAL To calibrate Inputs AI1 to AI3 as compared to an external measuring
device. Navigate past the inputs you don’t wish or need to calibrate.
•
MAn To manually command AV1 to AV3 (0-100% for tri-state or PWM, and
O
FF or ON for binary outputs), associated with OP1 to OP3 respectively.
This allows for end-to-end commissioning of output devices. Navigate
past the outputs you don’t wish or need to command. [When outputs are
defined as tri-state in the Configuration menu, modifications can only be
made to the primary output – the other output cannot be modified.]
•
bAL To enter Air Balancing mode, which is only an option when VAV is
selected as the Application in the Configuration Menu.
•
End To exit Service Tool mode (Yes or No). At any time within the Service
Tool menus, if you do not press a button within 30 minutes the device
will automatically revert to its normal temperature display mode (but
retains manually commanded outputs and stays in any forced VAV box
mode: MIN, MAX, CLOSED, OPEN).
Air Balancer Menu Options
Menu Item Description
BA
Displayed on line 1 of the LCD (top left) to indicate you are in the Air Balancer
Mode.
[Option] Air Balancer Mode has these following menu options, which you rotate through
using the arrow keys. Press the N
EXT or PREVIOUS buttons to penetrate deeper.
•
AF Displays the current Air Flow, and penetrating deeper allows you to
view the internal Air Flow Setpoint and the Air Flow Factor (with
possible adjustment).
•
MIn Displays the current Minimum Air Flow setting, and penetrating deeper
allows you to adjust the value and force the box to the minimum value.
•
MAM Displays the current Maximum Air Flow setting, and penetrating deeper
allows you to adjust the value, force the box to the maximum value, and
calibrate the display value to match a measured value.
•
CLO Penetrating deeper allows you to force the box fully closed and auto-
calibrate for zero flow.
•
Opn Penetrating deeper allows you to force the box fully open.
•
CtL Penetrating deeper puts the box back under control (releasing the box
from forced modes: MIN, MAX, CLOSED, OPEN, or ZERO Calibrate).
•
End To exit Service Tool mode (Yes or No). At any time within the Service
Tool menus, if you do not press a button within 30 minutes the device
will automatically revert to its normal temperature display mode (but
retains manually commanded outputs and stays in any forced VAV box
mode: MIN, MAX, CLOSED, OPEN, or ZERO Calibrate).
