Delta Controls DNS-24 User Manual

DNS-24, DNT-T103 & DNT-T221 Application Guide
Page 10 of 43 Document Edition 4.2
AV6 
Day Setpoint
Room Setpoint
ºC = 21; ºF = 71; % = 30
AV7 
Day Minimum
Minimum Adjustable Day Setpoint
ºC = 18; ºF = 65; % = 20
AV8 
Day Maximum
Maximum Adjustable Day Setpoint
ºC = 25; ºF = 77; % = 55
AV9 
Day Differential
Room Setpoint Differential
ºC = ±0.5; ºF = ±1, % = ±2.5
AV10 
Night Heat Setpoint
Night Setpoint for Heating (or Humidity)
ºC = 16; ºF = 60; % = 30
AV11 
Night Cool Setpoint
Night Setpoint for Cooling
ºC = 30; ºF = 86; % = 30
AV12
Application
Control Application (Name Changes)
None
AV13 
Alg Mode
Algorithm Mode
0 (OFF or Night)
AV14
Controller Status
Status of Internal Control Loop
N/A
AV15
Display Code
Local Display & Button Handling
1237
AV16
AI1 Calibration
Input 1 Calibration (Temperature)
0.0
AV17
AI2 Calibration
Input 2 Calibration (MUXed IP)
0.0
AV18
AI3 Calibration
Input 3 Calibration (Humidity)
0.0
AV19
Proportional Band
Control Loop Tuning Parameter
ºC = 1; ºF = 2; % = 10
AV20
Reset Rate
Control Loop Tuning Parameter
1.0
AV21
Output 1 Config
Output 1 Configuration Variable
As per Application Setup
AV22
Output 2 Config
Output 2 Configuration Variable
As per Application Setup
AV23
Output 3 Config
Output 3 Configuration Variable
As per Application Setup
AV24
Setup 1
Setup Variable 1 (Name Changes)
As required
AV25
Setup 2
Setup Variable 2 (Name Changes)
As required
AV26
Setup 3
Setup Variable 3 (Name Changes)
As required
AV27
Setup 4
Setup Variable 4 (Name Changes)
As required
AV28
Setup 5
Setup Variable 5 (Name Changes)
As required
AV29
Setup 6
Setup Variable 6 (Name Changes)
As required
AV30
Baud Rate
Network Baud Rate
*
AV31
PIN
PIN (4-Bit Configuration Access Code)
1011
AV32
Service Tool Mode
Service Tool Access Disable/Enable (0-2)
1 (or 2 when AV12 = VAV)
AV33 
Box Mode
Heating & Cooling Modes for VAV/VVT
0 (Cooling)
AV34
System Stats
System Statistics
N/A
AV35
System Log
System Event Log
N/A
AV36
AI4 Calibration
Input 4 Calibration (CO2)
0.0
AV38
Motion Latch
Configures the latch time for BI5
60 seconds
* Names are user settable (to a maximum of 32 characters), and only on outputs when they are controlled remotely (i.e.,
MUXed).
 These are the typical objects that may be commanded on the fly by a user or from GCL++, and also include the Outputs
(AV1-3) when they are MUXed. Never command the Configuration Variables (AV12, AV21-13) on the fly.
Device Object Commissioned Flag
Unlike DACs BACstats do not have individual commissioned flags for each I/O object. BACstats
have a single commissioned flag property in the device object which can be used during system
commissioning to indicate if the device has been commissioned.
Inputs
Humidity (AI3)
On BACstats with the on board humidity sensor option (H), the humidity sensor shows up as analog
input 3. When configured as a LINKnet device with display code 1111 input scaling is done in the
parent controller (see Appendix B LINKnet). Download the humidity scale range AIC from the DNS-
24 product page on the support site.
