3. CONFIGURATION MENU OPTIONS
The Configuration Menu is a list of items that you can navigate through to make changes for setup
purposes. The Configuration Menu items are as follows:
Menu Item
Description

Displayed momentarily to indicate you have successfully entered the Configuration
Menu.
[Application]
The Control Application (AV12). You may choose from any of the following
applications:
  This disables all control strategies and allows the outputs and control
icons to be controlled remotely from another device.
  This enables the VAV control strategy and allows you to configure the
outputs for your VAV application.
  This enables the VVT control strategy and allows you to configure the
outputs for your VVT application.
  This enables the HPU control strategy and allows you to configure the
outputs for your Heat Pump Unit application.
  This enables the FCU control strategy and allows you to configure the
outputs for your Fan Coil Unit application.
  This is no longer an option. Configure control for a Unit Heater using
the FCU application.
  This enables the Radiation control strategy and allows you to configure
the outputs for your Radiant Heating application.
  This enables the Humidity control strategy and allows you to configure
the outputs for your Humidity application.

Available when the Application = VAV. The air flow units setting (CFM or LPS)

Output 1 Configuration. This includes the output function and type (what it will
control and how) and other setup parameters as required (such as delays or limits).

Output 2 Configuration. This includes the output function and type (what it will
control and how) and other setup parameters as required (such as delays or limits).

Output 3 Configuration. This includes the output function and type (what it will
control and how) and other setup parameters as required (such as delays or limits).
[More]
Additional parameters to set, which are dependent on the Application and Output
Configuration, may include:
  Actuator Runtime in seconds (AV24)
  Air Flow Factor for VAV only (AV25)
  Minimum Air Flow for VAV and Damper Minimum for VVT (AV26)
  Maximum Air Flow for VAV and Damper Maximum for VVT (AV27)

The Temperature Units Setting (degrees C or F).
[Settings]
Additional control settings, which are particularly useful when an Application is
selected for local control, typically include:
  Day Setpoint (AV6)   Max. Day Setpoint (AV8)
  Day Differential (AV9)   CO Proportional Band (AV19)
  Min. Day Setpoint (AV7)   CO Reset Rate (AV20)
