Chapter 2 Creating and Editing Screens|ScrEdit Software User Manual
Revision Apr. 30th, 2007, 2007PDD23000002 2-97
Default tab in Configuration option
Element Font Color It is used to specify the default element font color when
creating an element.
Blink Time It is used to specify the default element twinkle time when
creating an element.
Scroll Size (if
Element has…)
It is available for the element that has scroll function, e.g.
Alarm History Table, etc. There are 20 pixels, 30 pixels and 40
pixels three options.
Table 2.9.5 Other Tab
Other tab in Configuration option
In Screen Management option on page 2-52, there is a more detailed description
for introducing how to drag the mouse to determine the screen saver display.
Enable Screen Saver This option should be selected when the user wants to
use Edit Save Screen function in Screen Management
option. If this option is not selected, even though the user
has chosen the Edit Save Screen function, the screen
saver will not be started up.
Screen Saver
Read Controller Address 1. The user can use this option to enable the screen
saver. When the setting value is 0, it indicates that the
screen saver function is disabled. If the setting value
is a non-zero value, it indicates that the screen saver
function is enabled. When the user touches the HMI
screen, the screen saver function is ineffective.
To Next Page
