Appendix A Specifications and Installation|ScrEdit Software User Manual
A-2 Revision Apr. 30th, 2007, 2007PDD23000002
MODEL AS38BSTD(-W) A(E)57BSTD(-W) A(E)57GSTD(-W) A(E)57CSTD(-W)
Vibration
Resistance
IEC61131-2 compliant
When vibration is NOT continuous: 5Hz-9Hz 3.5mm, 9Hz-150Hz 1G
When vibration is continuous: 5Hz-9Hz 1.75mm, 9Hz-150Hz 0.5G
X, Y, Z directions for 10 times
Dimensions
(W) x (H) x (D) mm
140.8 x 104.8 x 44.8 184.1 x 144.1 x 47
Weight Approx. 315g Approx. 768g
Operation Voltage DC +24V (-10% ~ +15%) (Please use isolated power supply)
(Note 3)
Backup Battery 3V lithium battery CR2032 x 1 / battery life: 5 years
Buzzer 85dB
NOTE
1) Only DOP-AE94BSTD this model is not UL recognized.
2) The maximum visual performance of the models with 256 colors LCD module is 256 colors. However, in
order to make the created elements to be displayed with more brilliant colors, the ScrEdit software
(Screen Editor, the program editor of Delta HMI product) only provides 144 colors for user settings.
3) Users please use isolated power supply except DOP-AE80THTD, DOP-AE94BSTD, DOP-AE10THTD
these models.
4) Users can download the Screen Editor, the program editor of Delta HMI product and the user manual via
the following link: http://www.delta.com.tw/industrialautomation/
.
