Delta Electronics A10 User Manual

Appendix A Specifications and Installation|ScrEdit Software User Manual
Revision Apr. 30th, 2007, 2007PDD23000002 A-3
MODEL A80THTD1 AE80THTD AE94BSTD
A10TCTD
AE10THTD
Operation System Windows Base Real Time OS
MCU 32-bit RISC Micro-controller / 206.4MHz
NOR Flash ROM NOR Flash ROM 8 Mbytes (System: 1MB / User: 7MB)
SDRAM 32 Mbytes 16Mbytes 32 Mbytes
Backup Memory
(Bytes)
512K 512K 512K
A：256K
AE：512K
SM Card
3 3
EXT.
Mem
ory
USB Disk
3 3 3
3（AE）
Extension Interface
3 3
3（AE）
USB for Download
[USB Client]
1 Client Ver 1.1
USB for Data
Storage / Printer
[USB Host]
3 3 3
3（AE）
Display Type
8” TFT LCD
(65536 colors)
8” TFT LCD
(65536 colors)
9.4” STN LCD
(8 shades of blue)
10.4” TFT LCD
(A：256 colors
AE：65536 colors)
Resolution 640 x 480 pixels
Back Light
2CCFL Back Light
(about 50 thousand hours at 25
o
C)
CCFL Back Light
(about 30 thousand
hours at 25
o
C)
2CCFL Back Light
(about 30 thousand
hours at 25
o
C)
LCD MODULE
Display Size
8 inches
(162.2 x 121.7mm)
8 inches
(162.2 x 121.7mm)
9.4 inches
(192.0 x 144.0mm)
10.4 inches
(211.2 x 158.4mm)
Function Key User defined key x 6
User defined key x
11
User defined key x 7
Perpetual Calendar
(RTC)
Built-in
Cooling Method Natural air circulation
Safety Approval
(Waterproof for
front panel)
IP65 / NEMA4 / CE, UL
(Note 1)
Operating Temp. 0°C to 50°C
Storage Temp. -20°C to +60°C
Ambient Humidity 10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
Vibration
Resistance
IEC61131-2 compliant
When vibration is NOT continuous: 5Hz-9Hz 3.5mm, 9Hz-150Hz 1G
When vibration is continuous: 5Hz-9Hz 1.75mm, 9Hz-150Hz 0.5G
X, Y, Z directions for 10 times
Dimensions
(W) x (H) x (D) mm
243.1 x 178.1 x 52.4 243.1 x 178.1 x 52.4 297.1 x 222.1 x 50.9 297.1 x 222.1 x 51.1
Weight Approx. 1147g Approx. 1147g Approx. 1930g Approx. 1721g
