Chapter 2 Creating and Editing Screens|ScrEdit Software User Manual
2-62 Revision Apr. 30th, 2007, 2007PDD23000002
Function Description
Setting The user can find this function only in DOP series HMI which supports
printer function. If the user wants to enable this function, setting the printer
in advance is necessary. Please go to Option > Configuration > Print
(Fig. 2.7.15) and select the printer first. When this function is enabled, if
one report list button is created and its assigned output device is a printer,
once the user presses the report list button, HMI will refer to the setting in
Hard Copy Region option and execute the screen-printing.
Top-Left
Hard Copy
Region
Right-Bottom
It is used to set the region of HMI printing area (also called Hard Copy
Region) and the unit is Pixel.
Base Screen Check the check
box next to
“Need a base
screen”
Every screen can specify any one of the editing screens as a base screen.
When the check box next to “Need a base screen” is checked, the base
screen will be moved to the back (behind all other elements) as a ground
picture. After compile operation is completed and the screen data is
downloaded to HMI, HMI will execute all of the elements on the base
screen correctly.
