Mechanical Installation
16
SAFETY
For UL2202 1st Edition safety
compliance in electric vehicle
applications, a 12AWG green
bonding wire must be attached from the M4
stud located on the charger (see page 6) to
the vehicle frame. This is for electric shock
safety. The recommended torque is 1.6±0.1N-
m. Alternatively, M6 star washers can be
used on the mounting holes to “bite” through
the paint on the base plate to make electrical
contact. The recommended torque for this
is 7.0N-m±0.2N-m. If used in an electric
vehicle application, UL2202 1st Edition and
the National Electrical Code (NEC) requires
the charger’s AC plug be located at least 18”
above the ground and the display should be
visible to the user.
NOTE: UL2202 1st Edition has
been obsoleted. This information is
provided only for reference. Typical
maximum surface temperature of
the QuiQ charger is 60°C (140°F).
