Delta-q QUIQ Series User Manual

Mechanical Installation
18
CABLE STRAIN
High strain on the AC Input Cord
combined with heating and cooling
over time may cause one or more
conductors in the cord to break and the
charger to fail. The recommended minimum
bend radius on all cables leaving the charger
is 60mm (2.36”). This is illustrated below on
the AC input cord.
If it is necessary to clamp the AC cord to
the machine, it is recommended to clamp
the AC attachment cord that is brought to
the QuiQ charger’s AC input, not the QuiQ
Series charger’s AC input cord itself. This
is to isolate any possible wear or damage to
the easily replaceable attachment cord, and
not the charger.
An illustration of this appears below:
