Delta-q QUIQ Series - Interlocks

Electrical Installation
26
INTERLOCKS
There are two types of interlocks
and both interlocks have their own
relay.
STANDARD INTERLOCK
• One wire interlock
• Referenced to battery negative
• Green wire on standard cable
•
Toggling can depend on installed
algorithm
• Use a recommended wetting circuit
SIGNAL INTERLOCK
• Three wire interlock
• Floating reference
•
Three wires are found in the Deutsch
connector (DT06-08SA) in the QuiQ ICON
• Toggling will always happen with
connection/disconnection of AC power
