Pin Configuration for Signal
Connector (Deutsch DT05-08SA)
CONN PIN
WIRE DIAMETER
AWG
DESC.
Black 10-12 12V Ground
Blue 10-16
Switched Output Enable
(Input)
Red 10-12 12V Unswitched Output
White 10-12 Switched Output
CONN PIN NOTES
Black
Blue
8-17 VDC on this pin activates the 12V
switched output pins
Red Always active 13.5V output
White
13.5V output activated by the switched output
enable
Electrical Installation
39

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Delta-q QUIQ Series and is the answer not in the manual?

Delta-q QUIQ Series Specifications

General IconGeneral
Input Voltage85-265 VAC
IP RatingIP66
Input Frequency45-65 Hz
Storage Temperature-40°C to +85°C
Cooling MethodNatural Convection
Operating Temperature-20°C to 50°C
ProtectionOvertemperature
Agency ApprovalsUL, CE
CommunicationCAN bus
