OPERATIONAL CONTROLS AND ADJUSTMENTS
OPERATION
“ON”,“ON”
“OFF”,“OFF”
Make sure that the switch is in the “OFF” position before plugging cord into outlet. Do not touch
the plug’s metal prongs when unplugging or plugging in the cord.
STARTING AND STOPPING THE DRILL PRESS
IMPORTANT: "OFF"
In the event of a power outage (such as a breaker or fuse trip), always move the switch to the “OFF”
position until the main power is restored.
FIRE HAZARD. To reduce the risk of
fire, use a 40 watt or less, 120 volt, reflector track-
type light bulb (not supplied). DO NOT USE a stan-
dard house hold light bulb. Do not allow the reflector
track-type light bulb to extend below the lamp
shade.
To reduce the risk of injury, turn unit off
and disconnect it from power source before installing
and removing accessories, before adjusting or when
making repairs.
A
FLEXIBLE LAMP
“ON”“OFF”
Fig. 26
SPINDLE SPEED ADJUSTMENT
ONLY
"ON"
A
B
Fig. 25A
Fig. 25B
Fig. 24A
A
Fig. 24B
