5.1.3 Relation Between the PLC Action and the Device Type
Device type
PLC action
Non-latched area Latched area
Device Y Other devices File register Other devices
Power: OFF→ON
Cleared Cleared Retained Retained
Restore to defaults
Cleared Cleared Cleared Cleared
STOP
↓
RUN*
1
This clears the
non-latched area
state.
Cleared Cleared Retained Retained
This retains the
non-latched area
state.
Retained Retained Retained Retained
RUN
↓
STOP*
1
This clears the
device Y state.
Cleared Retained Retained Retained
This retains the
device Y state.
Retained Retained Retained Retained
SM204 is ON.This clears all
non-latched areas.*
2
Cleared Cleared Retained Retained
SM205 is ON.This clears all
latched areas.*
2
Retained Retained Retained Cleared
*1: For state setups, see HWCONFIG in ISPSoft. The PLC STOP->RUN default is “clear the non-latched area
state”. The PLC RUN->STOP default is “clear the state of device Y”.
*2: The timing for clearing the SM is when SM turns from OFF to ON. After PLC completes clearing, the
system turns SM from ON to OFF.
