Delta AS200 Series

AS Series Operation Manual
9-72
_9
Instance
Attribute
Name
Access
Rule
Data Type Values Description
H’02 Number Available Get UINT H’0
The maximum number of
connections
H’03 Number Active Get UINT H’0
The number of connected
connections
9.8.5 Assembly Object (Class ID: 04 Hex)
This object binds attributes of multiple objects, which allows data to or from each object to be sent or received over a
single connection and can be used to bind input data or output data.
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
H’0E Get_Attribute_Single V V Read a single attribute
H’10 Set_Attribute_Single X V Edit a single attribute
 Class
 Class ID：H’04
 Instance
 H’00：Class Attribute
 H’64：I/O Connection Output 1
 H’65：I/O Connection Input 1
 H’66：I/O Connection Output 2
 H’67：I/O Connection Input 2
 H’72：I/O Connection Output 8
 H’73：I/O Connection Input 8
 H’74-H’7A Reserved
 H’80：Configuration 1
 H’81：Configuration 2
