AS Series Operation Manual
6-30
Before you change the status of a device, make sure the operation does not cause damage to
equipment or personnel.
The table below describes the items in the context menu. The Force command only applies to input and output
contacts.
Item Description
Set On Set the contact selected to ON
Set Off Set the contact selected to OFF
Rising-edge Trigger
No matter what the state of the selected contact is, the system sets the contact to
OFF, and then sets it to ON.
Falling-edge Trigger
No matter what the state of the selected contact is, the system sets the contact to
ON, and then sets it to OFF.
Force Force an input contact or output contact ON or OFF
Force Device List Force several input contacts or output contacts in the tables ON or OFF
To change the value in a device, right-click the device, click Change Present Value, and set a present value in
the Enter Present Value dialog box.
