9_
 Data Mapping
1. Start ISPSoft and create a new Monitor Table. Add devices that correspond to the master in the table.
2. Change the project to Online Mode and start to monitor the data mapping.
Monitoring from the master
5555
7CB6
00005555
00007CB6
0.000
0.000
Monitor from the slave
Master_Address Slave_Address
D0

ToAS_IO
（Instance ID=110）
D500

FromAS_IO
（Instance ID=100）
