Delta AS200 Series User Manual

AS Series Operation Manual
2-15
_2
#1
#2
AS332T-A
#1
TB1 Y0.0 Y0.2 Y0.4 Y0.6 Y0.8 Y0.10 Y0.12 Y0.14 C0 -
TB2
Y0.1
Y0.3
Y0.5
Y0.7
Y0.9
Y0.11
Y0.13
Y0.15
C0
-
#2
TB1
X0.0
X0.2
X0.4
X0.6
X0.8
X0.10
X0.12
X0.14
S/S
-
TB2
X0.1
X0.3
X0.5
X0.7
X0.9
X0.11
X0.13
X0.15
S/S
-
AS332P-A
#1
TB1 Y0.0 Y0.2 Y0.4 Y0.6 Y0.8 Y0.10 Y0.12 Y0.14 - C0
TB2
Y0.1
Y0.3
Y0.5
Y0.7
Y0.9
Y0.11
Y0.13
Y0.15
-
C0
#2
TB1
X0.0
X0.2
X0.4
X0.6
X0.8
X0.10
X0.12
X0.14
S/S
-
TB2 X0.1 X0.3 X0.5 X0.7 X0.9 X0.11 X0.13 X0.15 S/S -
AS324MT-A
#1
TB1 Y0.0+ Y0.1+ Y0.2+ Y0.3+ SG1 Y0.4 Y0.6 Y0.8 Y0.10 C0
TB2
Y0.0-
Y0.1-
Y0.2-
Y0.3-
SG1
Y0.5
Y0.7
Y0.9
Y0.11
C0
#2
TB1 X0.0+ X0.1+ X0.2+ X0.3+ SG0 X0.4 X0.6 X0.8 X0.10 S/S
TB2 X0.0- X0.1- X0.2- X0.3- SG0 X0.5 X0.7 X0.9 X0.11 S/S
 Spring clamp/MIL connector terminal block UB-10-IO32D for AS332T-A/AS332P-A/AS324MT-A
40
39
38 37
36
35
34 33
32
31
30 29
28
27
26 25
24 23
22 21
20 19
18
17
16 15
14
13
12 11
10
9
8 7
6
5
4 3
2
1
