ECML Series Servo Motor_Coil assembly
ECM L - S 16 08 A 2 D N S
Cooling type
A: Air cooling
L: Water cooling
N: N/A
Hall sensor type
A: Analog
D: Digital
Input voltage
2: 220V
3: 380V
Wiring method
A: Wiring method A
Number of coil sets
03: 3 sets
04: 4sets
05: 5sets
06: 6sets
08: 8sets
Magnetic way dimensions
16: Ø16 mm
20: Ø20 mm
25: Ø25 mm
32: Ø32 mm
Component type
Null: coil assembly
M: magnetic way
Name of the Series
Linear motor type
S = Shaft type coreless
Servo Type
L: Linear servo drive
Product Name
ECM: Electronic Commutation Motor
